    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional

    Ask Lasest Price
    Brand Name : AOTONG
    Certification : ISO,CCC
    Supply Ability : 500 Set/Sets per Month
    Price : $20,000.00/sets 1-1 sets
    Delivery Time : 25 days
    Payment Terms : TT
    • Product Details
    • Company Profile

    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional

    Product Description
    Customize the semi trailer according to your requirements.Professional semi trailer manufacturer with more tahan 20 years of production experience serve for you AOTONG
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    Product
    Detachable gooseneck lowbed semi trailer
    Size
    16000*(2500-3000)*800 (mm)
    Payload
    40000KG-10000KG
    Power pack
    Engine for hydraulic cylinders
    Main beam
    Heavy duty I beam.
    Side beam
    250mm I beam
    Plate
    4mm checked plate
    Ladder
    Small ladder frond loading
    Axles
    3 * 13ton capacity (Brand optional)
    Suspension
    Mechanical suspension (Air suspension optional)
    Leaf spring
    10pcs
    Tire
    12R22.5 / 11.00R20 12pcs (Other size optional)
    Rim
    9.00-22.5 / 11.00R20 12pcs (Other size optional)
    Kin pin
    2’’/3.5’’ bolt type
    Landing gear
    28 Ton two speed
    Braking system
    Double air chamber ,brake valve,45L air tanks ;ABS optional
    Electrical
    LED light , 7 ways ,24V
    Painting
    Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
    AOTONG low loader trailer can satisfy the concentrated force, the anti bump and the distortion resistance.
    AOTONG make sure that lowbed semi trailer can meet load requirements on different kind of roads and has a long service life.
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    We start from every detail, carefully craft to customize your high-quality semi trailer.
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    Excellent design abilityWe have many experienced designers, according to your needs to develop the most reasonable design and meet
    your customized needs.
    Click for your own design!
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    Popular Colors and High Quality Painting
    We use high quality paint to make our products beautiful, seamless, dustproof and easy to clean.KTL electrophoresis + powder
    spraying, instead of traditional paint process to make a good bond with a solid base, good wear resistance, durability and has
    good anti-corrosion effect and long paint life.
    Which color do you want to customize, click to get more!

    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
    3 Axle Front Load Low Bed Trailer with Hydraulic Detachable Gooseneck and ABS Optional
