Model

Outside Dimension

No. of Axle

Tire size

Tare Weight

Rated Load

(L×W×H)(mm)

(kg)

(kg)

LAT9325TDP

13000,12500X3000,2800X3150,1710

3

11.00R20 /12R22.5

8500

60000

Brand Name

Aotong Brand

Manufacture

Shandong JUYUAN Automobile Technology Co.,Ltd

Main Frame

Q345B manganese plates,automatic submerged arc welded

Floor

Steel Sheet 3mm thickness or diamond plate

(Also can choose other thickness,such as 2mm,2.3mm,4mm,5mm,6mm)

Axle

Brand: FUWA(BPW optional)

Suspension

Independent stamping steel rigid suspension( air suspension)

King Pin

2"or 3.5"traction pin made in China( Jost optional)

Landing Gear

chinese brand loading 28000kg (JOST optional)

Spare Wheel Carrier

One set of spare wheel carrier including a riser.

Braking System

Kemi or other Brand of China; ABS (optional )

Brake Air Chamber

Four double and two single chamber

Electrical System

1. Voltage: 24v 2. Receptacle: 7 ways(7 wire harness)

Painting

Sand blasting processing clean rust

1 coat of anticorrosive primer

2 coats of finish urethane paint

Color as customer choice

Accessory

One tooling box with a set of standard trailer tool

Usage

Is applicable for the transportations of the mechanical equipment,

large objects, highway construction equipment, large tanks,

power plant equipment or machine, and all sorts of steel products.
