Semi-Trailer Self-Propelled Modular Transporter Trailer for Bridge Beam Transport

Ask Lasest Price
Brand Name :	AOTONG
Certification :	ISO,CCC
Supply Ability :	10 Set/Sets per Month
Price :	$150,000.00/sets 1-1 sets
Delivery Time :	25 days
Payment Terms :	TT

Add to Cart

Product Details
Company Profile

Semi-Trailer Self-Propelled Modular Transporter Trailer for Bridge Beam Transport

Product Description

Customize the semi trailer according to your requirements.Professional semi trailer manufacturer with more than 30 years of production experience serve for you —AOTONG

Semi-Trailer Self-Propelled Modular Transporter Trailer for Bridge Beam Transport

★Construction machine , Mining equipments Wind blades , special bulk cargo transportation

★Customized require design for dimension, multi functionspecial purpose design
★Front loading ramp , folding gooseneck design optional

Brand	Aotong
Rated Capacity	35000kgs /Row @ 0.6Km/h
Tare Weight	3100 kgs/Row
Material	S690, AH60, 40Cr high tensile Steel
Loading Deck Height	1175±300mm
Width of Platform	2990mm-3000mm
Max Steering Angle	+/-55°
Brake	Dual line pneumatic brake system,T30/30+T30 air chamber; parking brake;
Electrical System	24V, 7core socket, lights according to European standards.
Wheelbase	1500mm
Tire	215/75R17.5
Rim	6.00-17.5 (10holes)
Approaching Angle	25°/ 28°
Suspension	Hydraulic Air suspension with lifting and steering / Axle Steering
Tire & Rims No /line	8 sets
Connection Platform	Optional by Cargo / Machine Size
Pin Height	According to the height of the tractor saddle.
Painting	Three coats painting; Any color will be available
Welding	automatic submerged arc welded
Lights	Rear light, rear reflector, turn indicative light, side
Lights		reflector, fog lamp, number plate light
Painting	Three coats painting; Any color will be available
Tool Box	One tool box with a set of standard trailer tools
Tyre Carrier	One piece
Electrical	1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) Euro Standard
Exw-factory	Wax -spray
Color and Logo	Depends on the buyer’s requirement.
Product Production	New Made and Stock Optional
Tool Box	1 box of standard tools
Spare tire carrier	2 sets

AOTONG semi trailer can satisfy the concentrated force, the anti bump and the distortion resistance.

AOTONG make sure that semi trailer can meet load requirements on different kind of roads and has a long service life.

AOTONG start from every detail, carefully craft to customize your high-quality semi trailer.

AOTONG low loader trailer can satisfy the concentrated force, the anti bump and the distortion resistance.

AOTONG make sure that lowbed semi trailer can meet load requirements on different kind of roads and has a long service life.

Excellent design ability!

We have many experienced designers, according to your needs to develop the most reasonable design and meetyour customized needs.
Click for your own design！

Strict load test before delivery！

Related Products

We also have rich production experience in the following models.

If this item is not what you like, then we suggest these items：

Click to get the models that have been shipped to your country！

2 axles lowbed semi trailer

3 axles lowbed semi trailer

4 axles lowbed semi trailer

Multi axles lowbed semi trailer

Extendable lowbed semi trailer

Detachable gooseneck semi trailer

Modular trailer

2/3/5 line 4/6/10 axles lowbed semi trailer

Lowbed trailer with removable fence

superlink lowbed semi trailer

Wind blade special trailer

Heavy equipment lowbed semi trailer

Our lowbed semi trailer ladder has a rib design to increase its load carrying capacity.
A variety of ladder can be selected, ordinary ladder, spring ladder, hydraulic ladder, hydraulic folding ladder. The spring ladder can be lowered by its own weight. Hydraulic ladder reduces labor strength. Folding the ladder will lower the up and down slope.

Packing&Shipping

In nude,Polish with water wax before shipment

1. By 40ft/45ft/40fr container

2. By bulk /roro ship

3. As your requirments.

Professional package saves freight cost for you. In order to prevent seawater corrosion,we will carefully Wrap film or covered tarpaulin.When goods arrive in Africa, Australia and even South America, they can maintain a good appearance.

High quality painting and professional transportation ensure good condition of goods. We believe that we can win-win by providing detailed services.
