vehicle name

2 axle gooseneck dumping semi-trailer

overall dimension(mm) (LxWxH)

112800×2495×3970

box dimension(mm) (LxWxH)

10500×2300×1500

Weight

Tare Weight

8.5T-10T

Payload

50T-70T(25 m³—37m³)

Specification

Axle Weight Load

13T/14T/16T/20T per axle

Axle number

2

Axle specs

FUWA,JINSHENG/BPW brand

Suspension

mechanical suspensions

King Pin

50#/90# traction pin

Lifting system

Full set of Hyva hydraulic system/ Full set of Jiuzhouzhongli hydraulic system

Steel Spring

10pieces

Landing Gear

28 ton capacity

Tire

Tire specs.

11.00R20-18

Number of Tire

8pieces

Spare Tire Carriers

2 pieces

Rim

8.00*22.5 , 8 pieces

Frame (specs. and materials)

Main frame is height 500mm

Frame Beam

Upper and lower plate is20mm, middle is10mm(Double+three plate). height is 500 mm

Frame Floor

The Thickness is 3mm flat bed

Brake

Brake System

Dual line braking system

Brake Chamber

Two double chamber/ABS

Brake valve

WABCO

Electrical System

1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)

Lamp

LED

Color

Any color will be available

Accessory

One tooling box with a set of standard trailer tool
