Brand Name : | AOTONG |
Price : | $17,500.00/pieces >=3 pieces |
Certification : | ISO,CCC |
Delivery Time : | 25 days |
Payment Terms : | TT |
Size | 9000*2500*1600 (mm) |
Side board height | optional |
Payload | 50000KG volume optional |
Main beam | Heavy duty I beam. |
Side wall | 6mm |
Floor | 8mm |
Cylinders | HYVA |
Axles | 3 * 13ton capacity (Brand optional) |
Suspension | Mechanical suspension (Air suspension optional) |
Leaf spring | 10pcs |
Tire | 12R22.5 12pcs (Other size optional) |
Rim | 9.00-22.5 12pcs (Other size optional) |
Kin pin | 2’’/3.5’’ bolt type |
Landing gear | 28 Ton two speed |
Braking system | Double air chamber ,brake valve,40L air tanks ;ABS optional |
Electrical | LED light , 7 ways ,24V |
![]() |
