Product Information

Product

side wall semi trailer

Brand Name

Aotong Brand

Announcement (batch)

229

Place of Origin

Shandong province, China

Color

Any color will be available

Manufacturer

Liangshan Juyuan special vehicle manufacturing Co., Ltd

Specifications

Parameter

Outside Dimensions (L*W*H)

(6000-17000)*2500*1550mm

Rated Load

45000 kg

Tare Weight

7000 kg

Wheel Base

8390+1310+1310 (mm)

Twist lock No

12

Running Gear

Tires

specification

12R22.5-18

No. of tires

8/12/16

Spare tire carriers

1 or 2

Axles

Brand

FUWA (BPW optional)

No. of axles:

2/3/4

Axle-load

13000kg

Wheel rim

7.50-20 rim or 8.00

Suspension

rigid suspension,10 pcs leaf-spring

Brakes

brand

TKL brand

Brake chamber

double air chamber

System

Dual line braking system /ABS

Under Frame

Departure Angle

16

Front/Rear Overhang

1890mm

Main Beam

material

I beam ,Q345B, automatic submerged arc welded

specification

Height is 500mm,upper plate is 14mm,lower plate is 16mm,middle is 8mm

Cross Beam material

Q235B

Side beam

Channel steel

Plate form

Steel Sheet 3mm thickness or diamond plate(Also can choose other thickness ,such as 2mm,2.3mm,4mm,5mm,6mm)

King Pin

50# or 90#

Landing gear

28Ton

Accessory

One tooling box with a set of standard trailer tool

Electrical

Voltage

24V

Receptacle

7 ways (7 wire harness)

Lights

Front corner marker lamp :red ;reflector lamp :white

Side marker :orange

Rear lamp :red; rear reflector :white; turn single lamp :orange

Painting ,marking and side guard can according to the customer’s requirement
