Product Specifications

Model Number

LAT****GRY

Total Weight

39950 kg

Rated Load

28500 kg

Tare Weight

9000 kg

Volume

20-75CBM

Heating system for bitumen trailer

diesel oil,coal or vapour

Compartment No & Valve

compartments is depends on the requirements. with loading

and unloading valves, loading and unloading pump.

Wheel Base

7000+1310+1310 (mm)

Tyre Specifications

12R22.5-18PR or as customer’s requirements

No. Of the Tyres

8/12/16

Axle Brand

FUWA (BPW,JINSHENG optional)

No. Of the Axles

2/3/4

Axle-load

24000 kg

King Pin

50#/90#

Landing Leg

28ton

Pieces of leaf-spring

10(8)

Suspension

independent stamping steel rigid suspension (or air suspension)

Departure Angle

14.8

Front/Rear Overhang

2080 mm

Outside Dimensions (mm)

13000X2500X3800 (LxWxH)

(Interior )Tank shell Dimensions (mm)

12800×2500×2300 (LxWxH)

Material of the Main Beam

Q345B manganese plates, automatic submerged arc welded

Brake System

Dual line braking system /ABS

Brake Air Chamber

Six double chamber

Electrical

24V 7 ways(7 wire harness)

Usage

The cargo's carrying part is tank-style designed, is suitable for

the transportation of liquid products

Characteristics

1. 1. High transport efficiency, ensuring the products will not

be deteriorated in the process of transportation, saving the

packing materials to reduce the transport costs.

1. 2. Equipped with gasification bed, intake control system,

and thrusting control system to ensure the pipelines unimpeded.

1. 3. The tanks bulbar and the horizontal sextant angle are greater

than the material rest angle, ensuring the discharging speed.

1. 4. The diesel engine (air compressor unit), providing compressed

air.

Other Specifications

The sealing head of the tank shell can be torque and ellipse,

and internal anti-wave plates are installed. Heat

preservation organization adopts the single-layer insulation by

using compressed thick glass fiber, with good presence and

light weight. The internal part can be single layer or dual layer
