    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring

    Ask Lasest Price
    Brand Name : AOTONG
    Price : $15,500.00/sets 1-4 sets
    Certification : ISO,CCC
    Delivery Time : 25 days
    Payment Terms : TT
    • Product Details
    • Company Profile

    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring

    Product Description
    Total Weight
    40000 kg
    Rated Load
    33000 kg
    Tare Weight
    7000 kg
    Wheel Base
    6810+1310+1310,6510+1310+1310 (mm)
    Tyre Specifications
    11.00R20 12PR
    12R22.5 12PR(Vacuum tyre or rail tyre)
    No. Of the Tyres
    12
    Axle Brand
    FUWA (BPW optional)
    No. Of the Axles
    3
    Axle-load
    24000 kg
    Pieces of leaf-spring
    10 (8) (4)
    Suspension
    Independent stamping steel rigid suspension ( air suspension)
    Departure Angle
    13.4
    Front/Rear Overhang
    2300 mm
    Outside Dimensions (LxWxH)
    13000X2500X4000, 3800,3600 3400,3200 (mm)
    Interior Dimensions (LxWxH)
    12800X2300X2600, 2400,2200 2000,1800 (mm)
    Material of the Main Beam
    Q235A manganese plates, automatic submerged arc welded
    Brake System
    ABS: RL122-1 (optional )
    Brake Air Chamber
    Four double and two single chamber
    Usage
    Suitable for the agricultural, sideline products and other light products' transportation. The design is convenient for products'
    unloading, and it's not only satisfy the rated load also reduce the burden of the compartments.



    Other Descriptions
    The cargo's carring part of the stake truck is store house bar style designed, the beam wears through the longitudinal beam which
    is welded as a space frame structure, making the frame strength, stiffness, flexibility an equilibrium, a strong carrying capacity
    without permanent deformation.
    Other Specifications
    The max height of the rear guard from ground is 550mm, and the cross section is 180mmX70mm.
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    Product packaging
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    Certifications
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    Details Images
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    Company Profile
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    Manufacturing Technique
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    Customer Photos
    3 Axle Fence Semi Truck Trailer with 90 W mm*13 Thickness mm*10 Layer Leaf Spring
    Why Choose Us
    1. Over 15 years professional manufacturer experiences

    2. Be designed according to your requirements

    3. CCC ISO9001 SGS agreement

    4. Small order can be accepted

    5. 1 year quality guarantee term

    6. We accept 100% inspection, welcome to our factory at any time
